Garden tractor loader cyl kit Johnson 14(2 cyl opt), 27, Kubota B219, Deere 20



Rebuild your Johnson Loader cylinders used on the Deere, Cub, Bolens and others. This kit is for the.

Johnson 27, 14 (with 2 diameter cylinders). Kubota B219 and Deere 20. These are the loadrs with 2 cylinders. Measured on the INSIDE diameter of the barrel, the. Will measure about 2 3/8-2 1/2" with the 3/16" wall thickness.

Tilt rods are 1 1/8. And lift rods are 1 1/8. Note: If you have a Johnson 10, 10TC. 12, 14with 1.5" diameter cylinder s1 7/8"-2 O. , please see my other listing for Johnson 10, 10TC, 12, 14 kit. Included in these kits are all the O-rings, backup O-rings and seals/wipers for the 2 lift and 2 tilt cylinders. To rebuild all four of your cylinders. I do include an exploded view for you to follow along. Of the o-rings and seals packaged together as they are easy to match up to the old for replacement. Are sourced for wipers/dust seals. These cylinders are some of the easiest to get apart because of the gland design and simple snap ring to. Many tractor addicts have repaired their own cylinders, using my kits, although they had never. Worked on hydraulic cylinders before. The only special tools needed are snap-ring pliers, a vise and a big. Wrench/adjustable wrench for the piston nut (about 1.5).

I have started carrying the retaining snap-rings for the glands. Most of my previous customers have reused theirs.
